Graphite block for sintering industry

Our Graphite Blocks, made from excellent petroleum coke, are widely used in metallurgy, machinery, electronics and chemical industry, etc. Various Graphite Blocks with qualified materials are available in our factory. We could supply medium-grain graphite, molded graphite, isostatic graphite, kinds of domestic and imported graphite, and so on. Typical sizes as follows: 400x400x1800mm; 500x500x1950mm, 500x330x1950mm, 500x430x1950mm, 520x350x2150mm, 630x630x2200mm, 600x500x2200mm, 820x340x2100mm, 520x350x2600mm, 1100x11000x350mm, etc.

Description

Item	Unit	Guarantee Value	Typical Value
Grain size	mm	0.8	0.8
Density	g/cm3	≥1.70	1.73
Resistance	ohm	≤8.5	7.5
Bending Strength	MPa	≥10.0	11.0
Compressive strength	MPa	≥24.0	17.0
Thermal conductivity	W(m.k)	≤120	150
C.T.E(100-600)℃	10-6/℃	≤2.5	2.2
Ash Content	%	≤0.3	0.09

Do you know the use of our graphite block?

The graphite block can use for making graphite plate, graphite rod, graphite tube, graphite crucible, graphite rotor and shaft and so on. It widely used in electron industry, chemical industry, mechanical industry, aviation industry, manufacturing industry, metallurgic industry and so on, such as anode, cathode, bipolar plate, vacuum furnace, water treatment, hydrogen fuel cell, electrode, casting, glass factory, heat conduction, lubricant, mold industry, vacuum pump.

Do you know how to choose the graphite block?

If you know the graphite and its specification very much, you could choose the best material according to our offered information.

If you don’t know the graphite and its specification very much, please kindly contact me. Then I will give you the best suggestion.

Some information need to be confirmed, such as size or drawing, use, working environment, in vacuum or air, working temperature and so on.

Looking for ward to your early contact.
